SmartPro Screen-I Synthetic Colorless Diamond Screener

Introduction

Screen-I is a portable diamond verification instrument designed for smart testing of Natural Diamonds (Type Ia) from Synthetic Diamonds HPHT / CVD (Type IIa) from Colourless to Near Colourless ( D to J ). Its capable of checking the mounted stones (mounted jewellery with under hole only). Screen-I is manually operated but gives an automatic test result. Moreover, it lasted around 150 hours on heavy use for more enjoyable testing.

Features

• Can screen Natural Diamonds (Type Ia) from Synthetic Diamonds HPHT / CVD (Type IIa)
• Designed for Colourless to Near Colourless ( D to J )
• Can test from 0.01 CT up to 12 CT
• Smart Touch Test Switch
• Laser Target Pointer
• Auto Testing Function
• Result Indicating by bright LED lights with sounds
• Automatic Power OFF (after 5 minute inactive)
• Ready LED indicator
• Low Battery Indicator
• Buzzer sound Indicator
• Bluetooth Ready Device to connect on Smartpro Mobile Application (may use in getting test result and issue certificates)

Benefits

• Capable of checking the mounted stones (mounted jewellery with under hole only)
• New technology LED light source with high efficiency and mercury-free
• No warm up time before testing
• Super battery life saver

Power and Battery

• Input Power Source: 4 x AAA Batteries or USB Power Adaptor

Optional Accessories

• None (all are included in the package)

Dimensions and Weight

• Length: 12.6 cm
• Width: 7.6 cm
• Height: 6.5 cm
• Weight: 153 g.

Included Accessories

• SmartPro Screen I (SPS I)
• Micro USB Cable
• Protective Carry Case
• User Manual Book
• Warranty Card

Operating Conditions

• Operating temperature: 0C 35C ( 32F 95F )
• Storage temperature: -20C 40C ( -4F 113F )

Technical Specifications

• Rated Power: VDC 5 6V / 1 2 A
• Standby Time: 5 min from the last measurement
• USB Input Port Type: Micro USB Type A-B
• USB Cable Type: USB 2.0 type A To Micro USB type B
• Time Duration per test: 3 sec.
• Battery life test: Up to 150 hours of continuous
  use based on alkaline batteries

makes every attempt to provide accurate information for each item. Actual packaging and/or specifications may be slightly different from the information and picture provided.
